SPECIFICATIONS

CapacityCopper Tube: 1⁄2 - 2 1⁄2" (12 - 65 mm). Steel Pipe: 1⁄2 - 2" (12 - 50 mm)

CompressorRotary, 230V, 50 Hz, 2.4A, 505W

RefrigerantR-507

Weight55 lbs (25 kg)

Hose Length2,6 m ( 5,2 m span)

Dimensions22 7⁄8" (58 cm) x 11" (28 cm) x 14 1⁄2" (37 cm) (L x W x H)

Model SF-2500 SuperFreeze

Pipe Freezing Tool Avoids the Cost and Inconvenience of a System Shutdown and Purge.

The SuperFreeze Pipe Freezer is an easy-to-use pipe freezing unit that allows the contractor to keep water systems operating while making repairs. The RIDGID Model SF-2500 is a mini-refrigeration unit that circulates self-contained refrigerant to its aluminum freeze heads. This forms an ice plug in as little as 6 minutes in 1⁄2" (12 mm) copper tube and can be used with up to 2 1⁄2" (65 mm) tube or 2" (50 mm) steel pipe. Once the pipe is plugged, repairs can be made while the ice plug is maintained by the unit. Now includes a bottle of specially formulated freeze gel to speed freezing. Apply the gel to freeze heads before placing on pipe.
