FEATURES

Lightweight and compact design is one-half the size of popular inspection systems, easily stowed in a truck and carried onto the jobsite
Multi-monitor compatibility with existing SeeSnake monitors, or the micro CA-300 digital inspection camera
Durable and reliable construction with hardened stainless steel camera head spring assembly for a long service life as well as long lasting high-intensity lights for exceptional viewing
Ideal for inspections with tight turns such as toilet traps and P-traps

SPECIFICATIONS

SeeSnake microDrain

D30 & D65S System

Camera Head: 0.86" (22 mm)

Cable Length: 30' (10 m), 65' (20 m)

Cable Diameter: 0.33" (8,3 mm)

Line Capacity: 1¼" to 3 / 4" (32 - 75 / 100 mm)

Weight: 8.6 lbs. (3,9 kg), 9.8 lbs. (4,4 kg)

Length: 13.25" (33,7 cm)

Width: 6.6" (16,8 cm)

Height: 14.2" (36,1 cm)

Resolution: 628 x 586 NTSC

Ball guide: 2 Included

Sonde: Standard with 20 m microDrain, 512 Hz.

Counter: NA

1¼" to 3 / 4" (32 - 75 / 100 mm)* lines up to 65' (20 m)

Passes multiple 90° bends in most 1.5" (40 mm) drain lines

SeeSnake microDrain™ video inspection system provides small size and maneuverability for small diameter and tight-turn radius inspections.

* 3" (75 mm) when used with a microEXPLORER or micro CA-300. 4" (100 mm) when used with a SeeSnake monitor.
